Suspension Clamp

Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor

Certification
CE
Model Number
ZCPC
Packaging Details
50pcs/ctn , 50x21x21cm , 15kgs
Supply Ability
100000PCS/Month
Material
Thermoplastic Aluminum Alloy Hook
IEC Standard
NFC 33-040
Contact Now
Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor
Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor1 Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor2 Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor3 Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor4

Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor

Applicaiton:

ZCPC Suspension Clamp is suitable for connection or suspension between the two-core and four-core self-supporting insulated wire.For the installation and suspension of 4- core ABC cables from poles with standard hook attachment. For straight lines and depending on cross section, angles up to 15/30 degrees.Structure itself provide installation without any tools. Clamp including composite parts is protected form wearing in hook attachmentpoint

Features:

  1. The clamp complete the transformation between anchoring clamps and supporting clamps by adjusting bolt.
  2. The surface is special which can guarantee fastness, skid resistance and insulation.
  3. The body materials are UV-resistant.

Low Voltage Overhead Line Solutions UV Black Thermoplastic Suspension Clamp Assembly For 4 Core Insulated Conductor

Item No. Cross section(mm2) Material Conductor(mm) Breaking load
ZCPC 2x(25-35)-4x(16-120) Nylon,Steel 12-42 8KN
