Screw Wired 7P 24V Alumium Body Auto Trailer Connector N Type For Tractor Use
- Certification
- CE and ROHS
- Model Number
- ZC6003,ZC6038
- MOQ
- 1000PCS
- Packaging Details
- 100PCS/CTN
- Supply Ability
- 200000PCS/Month
- Material
- Aluminum Body +Brass Contact
- Color
- Silver
- Poles
- 7pins
- Voltage
- 24V
- Type
- European Trailer Plug
- Gender
- Male
- Wire
- Screw Wire
Screw Wired 7P 24V Alumium Body Auto Trailer Connector N Type For Tractor Use
Product Function:
1.Criss-cross of slotted brass contact, matched with female needle.
2. The surface is matte process and new material.
3. Appearance design is convenient and easy.
| Type | European Trailer Plug |
| Model NO. | ZC6003 |
| Gender | Male |
| Color | Silver |
| Voltage | 24V |
| Body Material | Aluminum |
| Contact materials | Brass Conact |
| Pin | 7 pin |
| Wire Method | Screw Install |
| certification | CE, ROHS, PAHS |
| Aplication | Automotive,Trailer,Truck,Yacht and so on |
Specifications:
7 Pin Lighting Connections - 12 N Black Cable Function
PIN 1 - Yellow Wire (Left/H Direction Indicator)
PIN 2 - Blue Wire ( Rear Fog Lamps )
PIN 3 - White Wire ( Earth Return )
PIN 4 - Green Wire (Right/H Direction Indicator)
PIN 5 - Brown Wire (Right/H Tail & No. Plate Lamp )
PIN 6 - Red Wire (Brake lights)
PIN 7 - Black Wire (Left/H Tail & No. Plate Lamp )
