24V ABS/EBS Trailer Plug Socket Connector

Euro 7P 24V ABS / EBS Trailer Plug Connector For Auto Trailer Car

Certification
CE and ROHS
Model Number
ZC6009
MOQ
1000PCS
Packaging Details
100PCS/CTN
Supply Ability
200000PCS/Month
Material
Nylon66 plastic + Brass Contact
Color
Black
Poles
7pins
Voltage
24V
Type
European ABS EBS Trailer connector
Gender
Male
Wire
Screw Wire

Contact Now

24V ABS trailer connector



Euro 7P  24V ABS / EBS Trailer Plug Connector For Auto Trailer Car

Product Function:

1.Criss-cross of slotted brass contact, matched with female needle.

2. The surface is matte process and new material.

3. Appearance design is convenient and easy.

Type  European ABS /EBS Trailer Connector
Model NO.  ZC6009
Gender   Male
Color   Black
Voltage  24V
Body Material  Nylon 66 Plastic
Contact materials Brass contact
Pin 7 pin
Wire Method  Screw Install
certification  CE, ROHS, PAHS
Aplication  Automotive,Trailer,Truck,Yacht and so on





EBS Trailer connector
Specifications:

7 Pin Lighting Connections - 12 N Black Cable Function

PIN 1 - Yellow Wire (Left/H Direction Indicator)
PIN 2 - Blue Wire ( Rear Fog Lamps )
PIN 3 - White Wire ( Earth Return )
PIN 4 - Green Wire (Right/H Direction Indicator)
PIN 5 - Brown Wire (Right/H Tail & No. Plate Lamp )
PIN 6 - Red Wire (Brake lights)
PIN 7 - Black Wire (Left/H Tail & No. Plate Lamp )
